09181349622
Manufacturer
HARTING Elektronik
Description
Conn IDC Connector HDR 34 POS 2.54mm Solder RA Side Entry Thru-Hole
Datasheet
DownloadProduct Attributes
Type
Color
Connector Type
Contact Resistance
Current Rating
Depth
Flammability Rating
Hole Diameter
Housing Color
Housing Material
Insulation Resistance
Lead Free
Lead Length
Lead Pitch
Length
Material
Max Current Rating
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Positions
Number of Rows
Orientation
PCB Thickness
Pitch
REACH SVHC
RoHS
Row Spacing
Termination
Test Voltage
Width
Description
Grey
Cable, IDC
15 mΩ
1 A
6.1 mm
UL94 V-0
1 mm
Grey
Polybutylene
10 MΩ
Lead Free
3.3 mm
2.54 mm
48.48 mm
PBT, Resin, Thermoplastic
1 A
105 °C
-55 °C
PCB, Through Hole
34
34
34
2
Straight
127 mm
2.54 mm
No
Compliant
2.54 mm
Through Hole
1 kV
48.48 mm
₹237.90
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹237.90
₹237.90
10
₹201.94
₹2019.40
25
₹189.30
₹4732.38
50
₹180.24
₹9011.83
100
₹171.21
₹17121.48
