09185066914

Manufacturer

HARTING Elektronik

Description

SEK 18 Series, 2.54mm Pitch 6 Way 2 Row Straight PCB Header, Solder Term, 1A

Datasheet

download datasheetDownload

Product Attributes

Type

Color

Connector Type

Contact Gender

Contact Mating Length

Contact Plating

Contact Resistance

Current Rating

Depth

Fastening Type

Housing Material

Lead Free

Lead Length

Length

Max Current Rating

Max Operating Temperature

Min Operating Temperature

Mount

Number of Contacts

Number of Pins

Number of Positions

Number of Rows

Orientation

Pitch

RoHS

Row Spacing

Schedule B

Termination

Description

Grey

Connector, Male Pin

Male

5.7912 mm

Gold

20 mΩ

2 A

8.5 mm

Latch

Polybutylene

Lead Free

29 mm

27.2 mm

1 A

125 °C

-55 °C

Through Hole

6

6

6

2

Straight

2.54 mm

Compliant

2.54 mm

8536694040, 8536694040|8536694040|8536694040|8536694040|8536694040

Solder

In Stock

Quantity

MOQ : 1

Minimum Qty : 1

decrement quantity
increment quantity

Per Unit Price

₹207.32

Total Price

₹207.32

delivery

Ships in 7-10 days from Bengaluru

Add to List

Quantity

Unit Price

Ext. Price

1

₹207.32

₹207.32

10

₹176.70

₹1767.05

25

₹176.72

₹4418.06

50

₹176.70

₹8835.23
