1-825437-2
Manufacturer
TE Connectivity / AMP
Description
Conn Unshrouded Header HDR 12 POS 2.54mm Solder RA Side Entry Thru-Hole Carton
Datasheet
DownloadProduct Attributes
Type
Approvals
Connector Type
Contact Current Rating
Contact Gender
Contact Material
Contact Plating
Contact Shape
Contact Style
Current Rating
Depth
ELV
Flammability Rating
High Speed Serial Data Connector
High Temperature Housing
Housing Color
Housing Material
Insulation Resistance
Keyed
Lead Length
Length
Lifecycle Status
Mating Post Length
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Positions
Number of Rows
Orientation
Packaging
PCB Mounting Orientation
Pitch
Plating Thickness
Radiation Hardening
RoHS
Row Spacing
Termination
Description
CSA
Header, Pin, Plug
5 A
Male
CuZn
Gold, Tin
Square
Pin
5 A
11 mm
Compliant
UL94 V-0
No
No
Green
PBT
5 GΩ
No
3.19786 mm
30.48 mm
Production (Last Updated: 3 days ago)
6.7 mm
105 °C
-65 °C
Through Hole
12
12
1
Right Angle
Carton
Right Angle
2.54 mm
2.5 µm
No
Compliant
2.54 mm
Through Hole
In Stock
Quantity
MOQ : 1
Minimum Qty : 1
Per Unit Price
₹171.64
Total Price
₹171.64
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹171.64
₹171.64
10
₹140.39
₹1403.92
25
₹140.41
₹3510.24
50
₹140.43
₹7021.35
100
₹108.74
₹10873.99
500
₹108.75
₹54372.60
1000
₹108.01
₹108014.62
