2005280100
Manufacturer
Molex
Description
10 Position FFC, FPC Connector Contacts, Bottom 0.039" (1.00mm) Surface Mount, Right Angle
Datasheet
DownloadProduct Attributes
Type
Flat Flex Type
Mounting Type
Connector Type
Number of Positions
Pitch
Termination
FFC, FCB Thickness
Height Above Board
Locking Feature
Cable End Type
Contact Material
Contact Plating
Housing Material
Actuator Material
Features
Voltage Rating
Max Operating Temperature
Flammability Rating
Description
FFC, FPC
Surface Mount, Right Angle
Contacts, Bottom
10
0.039" (1.00mm)
Solder
0.30mm
0.075" (1.90mm)
Flip Lock
Straight, Tabbed
Phosphor Bronze
Gold
Liquid Crystal Polymer (LCP), Glass Filled
Polyamide (PA), Nylon, Glass Filled
Solder Retention, Zero Insertion Force (ZIF)
125V
-40°C ~ 105°C
UL94 V-0
₹207.71
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹207.71
₹207.71
10
₹176.50
₹1765.04
25
₹165.43
₹4135.80
50
₹157.51
₹7875.40
100
₹149.98
₹14997.76
500
₹133.86
₹66931.34
1000
₹127.48
₹127475.05
Product Attributes
Type
Flat Flex Type
Mounting Type
Connector Type
Number of Positions
Pitch
Termination
FFC, FCB Thickness
Height Above Board
Locking Feature
Cable End Type
Contact Material
Contact Plating
Housing Material
Actuator Material
Features
Voltage Rating
Max Operating Temperature
Flammability Rating
Description
FFC, FPC
Surface Mount, Right Angle
Contacts, Bottom
10
0.039" (1.00mm)
Solder
0.30mm
0.075" (1.90mm)
Flip Lock
Straight, Tabbed
Phosphor Bronze
Gold
Liquid Crystal Polymer (LCP), Glass Filled
Polyamide (PA), Nylon, Glass Filled
Solder Retention, Zero Insertion Force (ZIF)
125V
-40°C ~ 105°C
UL94 V-0
