22-01-3087
Manufacturer
Molex
Description
Header Connector, cable Mount, plug, 8 Contacts, skt, 0.1 Pitch, idc Terminal |Molex 22-01-3087
Datasheet
DownloadProduct Attributes
Type
Approvals
Body Material
China RoHS
Color
Connector Type
Contact Gender
Contact Material
Contact Resistance
Country of Origin
Current Rating
Depth
Dielectric Material
Flammability Rating
Gender
Glow Wire Compliant
Halogen Free
Height
Housing Color
Housing Material
Insulation Resistance
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Current Rating
Max Operating Temperature
Min Operating Temperature
Mount
Number of Circuits
Number of Contacts
Number of Pins
Number of Positions
Number of Rows
Operating Force
Orientation
Packaging
Pitch
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Termination
Voltage Rating
Width
Wire Gauge (Max)
Wire Gauge (Min)
Description
CSA, UL
Nylon, Polyamide
Compliant
White
Plug, Socket
Female
Brass, Bronze
10 mΩ
US
4 A
12.7 mm
Polyamide
UL94 V-0
Receptacle
Non-compliant
Low Halogen
4.82 mm
White
Nylon
1 GΩ
Lead Free
20.88 mm
Production (Last Updated: 4 years ago)
ACTIVE (Last Updated: 4 years ago)
4 A
105 °C
-40 °C
Cable
8
8
8
8
1
7.8 N
Straight
Bulk
2.54 mm
No
Yes
Compliant
8536695050, 8536695050|8536695050, 8536695050|8536695050|8536695050, 8536695050|8536695050|8536695050|8536695050
Crimp
250 V
4.82 mm
22 AWG
30 AWG
In Stock
Quantity
MOQ : 4
Per Unit Price
₹27.04
Total Price
₹108.16
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹108.16
₹108.16
10
₹19.44
₹194.43
25
₹19.44
₹486.09
50
₹19.44
₹972.17
100
₹16.96
₹1695.70
500
₹15.95
₹7974.35
1000
₹15.00
₹14995.47
