3-1971800-3
Manufacturer
TE Connectivity
Description
Conn Shrouded Header (4 Sides) HDR 3 POS 2.5mm Solder ST Top Entry Thru-Hole Bag/Box
Datasheet
DownloadProduct Attributes
Type
Color
Connector System
Connector Type
Contact Current Rating
Contact Finish Thickness - Mating
Contact Gender
Contact Material
Contact Plating
Contact Shape
Contact Style
Current Rating
ELV
Fastening Type
Flammability Rating
Height
Housing Color
Housing Material
Length
Lifecycle Status
Manufacturer Lifecycle Status
Mating Retention
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Positions
Number of Rows
Operating Supply Voltage
Orientation
Packaging
PCB Mount Alignment
PCB Mounting Orientation
PCB Mount Retention
PCB Thickness
Pitch
Plating
Plating Thickness
RoHS
Sealable
Tab Width
Tail Length
Termination
Underplate Material
Voltage Rating
Wire Gauge (Max)
Wire Gauge (Min)
Description
Red
Wire-to-Board
Header, Plug, Tab
3 A
2 µm
Male
Brass
Tin
Square
Straight
3 A
Compliant
Latch
UL94 V-0
7.38 mm
Red
Nylon
9.906 mm
Production (Last Updated: 3 days ago)
ACTIVE (Last Updated: 3 days ago)
With
221 °C
-22 °C
Through Hole
3
3
1
50 V
Vertical
Box
With
Vertical
With
2 mm
2.5 mm
Tin
2 µm
Compliant
No
500.38 µm
3 mm
Solder
Nickel
50 V
28 AWG
22 AWG
In Stock
Quantity
MOQ : 4
Minimum Qty : 4
Per Unit Price
₹25.58
Total Price
₹102.33
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹102.34
₹102.34
10
₹21.97
₹219.67
25
₹22.02
₹550.49
50
₹22.02
₹1100.99
100
₹18.09
₹1808.51
500
₹15.67
₹7837.47
1000
₹15.03
₹15025.63
