5-1825137-2
Manufacturer
TE Connectivity
Description
Switch Toggle ON OFF (ON) SPDT Long Baton Toggle Wire Lug 5A 250VAC 28VDC Panel Mount with Threads Bulk
Datasheet
DownloadProduct Attributes
Type
Actuator Length
Actuator Material
China RoHS
Color
Contact Current Rating
Contact Material
Contact Plating
Contact Resistance
Contact Voltage Rating (AC)
Current Rating
Electrical Life
ELV
Flammability Rating
Height
Insulation Resistance
Isolation Voltage
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Min Operating Temperature
Mount
Number of Positions
Packaging
REACH SVHC
RoHS
Schedule B
Sealable
Termination
Throw Configuration
Voltage Rating (AC)
Width
Description
17.4498 mm
Phenolic
Non-Compliant
Red
5 A
Copper
Silver
10 mΩ
120 V
2 A
40 kcycles
Compliant
UL94 V-0
8.89 mm
1 GΩ
1 kV
12.7 mm
Production (Last Updated: 4 days ago)
ACTIVE (Last Updated: 4 days ago)
5 A
85 °C
250 V
28 V
-30 °C
Bushing, PCB, Panel
3
Bulk
No
Compliant
8536509065, 8536509065|8536509065|8536509065|8536509065|8536509065
EPOXY TERMINAL SEALED
Lug
SPDT
250 V
12.7 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹520.27
Total Price
₹520.27
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹520.27
₹520.27
10
₹462.92
₹4629.18
25
₹439.37
₹10984.15
50
₹423.59
₹21179.64
100
₹403.32
₹40332.18
500
₹437.29
₹218646.28
