615R100GAD10
Manufacturer
Vishay
Description
1nF 10 kV dc Ceramic Single Layer Capacitor, Y5R Dielectric Radial 615R Series
Datasheet
DownloadProduct Attributes
Type
Capacitance
Case/Package
Composition
Contact Plating
Depth
Dielectric
Dielectric Material
Height
Lead Diameter
Lead Pitch
Length
Lifecycle Status
Max Operating Temperature
Min Operating Temperature
Mount
Number of Pins
Number of Terminals
REACH SVHC
RoHS
Schedule B
Terminal Pitch
Termination
Tolerance
Voltage Rating
Voltage Rating (DC)
Width
Description
1 nF
Radial
Ceramic
Tin
8.1 mm
Y5R
Ceramic
23.9 mm
810 µm
12.7 mm
19.1 mm
Production (Last Updated: 9 months ago)
105 °C
-25 °C
Through Hole
2
2
Unknown
Compliant
8532230060, 8532230060|8532230060|8532230060|8532230060|8532230060
12.7 mm
Radial
20 %
10 kV
10 kV
8.1 mm
₹654.23
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹654.23
₹654.23
10
₹502.61
₹5026.10
25
₹502.63
₹12565.69
50
₹502.66
₹25133.22
100
₹404.99
₹40498.82
500
₹404.98
₹202492.24
1000
₹397.30
₹397300.32
