74435588200
Manufacturer
Wurth Elektronik
Description
Inductor Power Shielded Wirewound 82uH/76uH 20% 100KHz Ferrite 7A 0.0304Ohm DCR T/R Automotive AEC-Q200
Datasheet
DownloadProduct Attributes
Type
Ambient Temperature Range High
Ambient Temperature Range Low
Case/Package
Composition
Core Material
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Length
Max DC Current
Max Operating Temperature
Min Operating Temperature
Mount
Number of Pins
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Width
Description
75 °C
-40 °C
2212
Wirewound
Zinc
7 A
30.4 mΩ
22.5 mm
12 mm
12.3952 mm
82 µH
20 %
Lead Free
22.5 mm
7 A
125 °C
-40 °C
Surface Mount
2
Unknown
7 A
Compliant
7.75 A
4.4 MHz
30.4 Ω
Shielded
SMD/SMT
100 kHz
20 %
22 mm
₹765.96
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹765.96
₹765.96
10
₹751.35
₹7513.48
25
₹708.05
₹17701.18
50
₹699.11
₹34955.75
100
₹699.12
₹69912.40
