75867-104LF
Manufacturer
Amphenol Communications Solutions
Description
Conn Shrouded Header (4 Sides) HDR 20 POS 2.54mm Solder RA Side Entry Thru-Hole Quickie Tube
Datasheet
DownloadProduct Attributes
Type
Color
Connector Type
Contact Material
Contact Mating Length
Contact Plating
Depth
Flammability Rating
Gender
Hole Diameter
Housing Color
Housing Material
Insulation Resistance
Lead Free
Lead Length
Lead Pitch
Length
Mating Post Length
Max Operating Temperature
Max Voltage Rating (AC)
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Poles
Number of Positions
Number of Rows
Orientation
Pitch
REACH SVHC
RoHS
Row Spacing
Termination
Voltage Rating
Width
Description
Blue
Male Pin
Bronze
5.9944 mm
Gold
13.91 mm
UL94 V-0
Male
1 mm
Blue
Thermoplastic
100 GΩ
Lead Free
3.05 mm
2.54 mm
32.61 mm
6 mm
125 °C
500 V
-65 °C
Through Hole
20
20
20
20
2
Right Angle
2.54 mm
No
Compliant
2.54 mm
Solder
500 V
9.57 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹162.31
Total Price
₹162.31
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹162.31
₹162.31
10
₹129.29
₹1292.91
25
₹129.29
₹3232.27
50
₹129.29
₹6464.54
100
₹109.28
₹10928.37
