76384-306LF
Manufacturer
Amphenol Communications Solutions
Description
Dubox2.54mm, Board to Board Connector, Shrouded Header, Single Row, Straight.
Datasheet
DownloadProduct Attributes
Type
Color
Connector Type
Contact Material
Contact Mating Length
Contact Plating
Current Rating
Depth
Fastening Type
Gender
Housing Color
Housing Material
Insulation Resistance
Lead Free
Lead Length
Length
Mating Post Length
Max Operating Temperature
Max Voltage Rating (AC)
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Positions
Number of Rows
Orientation
Pitch
Radiation Hardening
REACH SVHC
RoHS
Termination
Voltage Rating
Width
Description
Black
Male Pin
Copper
5.0038 mm
Gold
3 A
5 mm
Friction
Male
Black
Thermoplastic
100 GΩ
Lead Free
3.4 mm
14.24 mm
5 mm
125 °C
1 kV
-40 °C
Through Hole
6
6
6
1
Straight
2.54 mm
No
No
Compliant
Solder
1 kV
4.7 mm
₹103.60
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹103.60
₹103.60
10
₹88.68
₹886.77
25
₹88.68
₹2216.92
50
₹88.68
₹4433.84
100
₹75.94
₹7593.84
500
₹68.18
₹34088.94
