825440-3
Manufacturer
TE Connectivity
Description
Conn Unshrouded Header HDR 6 POS 2.54mm Solder ST Top Entry Thru-Hole Carton
Datasheet
DownloadProduct Attributes
Type
China RoHS
Color
Connector Type
Contact Current Rating
Contact Gender
Contact Material
Contact Plating
Contact Shape
Contact Style
Current Rating
Depth
ELV
Flammability Rating
Gender
High Speed Serial Data Connector
High Temperature Housing
Housing Color
Housing Material
Insulation Resistance
Keyed
Lead Length
Lead Pitch
Lifecycle Status
Manufacturer Lifecycle Status
Mating Post Length
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Poles
Number of Ports
Number of Positions
Number of Rows
Orientation
Packaging
PCB Mounting Orientation
PCB Thickness
Pitch
Plating Thickness
Radiation Hardening
REACH SVHC
RoHS
Row Spacing
Schedule B
Shielding
Terminal Pitch
Termination
Description
Compliant
Green
Header, Pin, Plug
5 A
Male
Brass, CuZn
Gold, Tin
Square
Pin
5 A
6.15 mm
Compliant
UL94 V-0
Male
No
No
Black, Green
PBT
5 GΩ
No
3.19786 mm
2.54 mm
Production (Last Updated: 1 week ago)
ACTIVE (Last Updated: 1 week ago)
6.7 mm
105 °C
-65 °C
Through Hole
6
6
3
1
6
2
Vertical
Carton
Vertical
62 µm
2.54 mm
800.1 nm
No
Yes
Compliant
2.54 mm
8536694040, 8536694040|8536694040, 8536694040|8536694040|8536694040, 8536694040|8536694040|8536694040|8536694040
No
2.54 mm
Through Hole
In Stock
Quantity
MOQ : 1
Per Unit Price
₹103.15
Total Price
₹103.15
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹103.15
₹103.15
10
₹83.14
₹831.40
25
₹83.19
₹2079.84
50
₹83.19
₹4159.68
100
₹67.84
₹6783.71
500
₹67.83
₹33916.76
1000
₹63.67
₹63673.83
