97-3101A-16S-1P
Manufacturer
Amphenol Industrial
Description
Conn MIL-C-5015 Circular PIN 7 POS Solder ST Cable Mount 7 Terminal 1 Port
Datasheet
DownloadProduct Attributes
Type
Approvals
Body Material
Body Plating
Case/Package
Connector Type
Contact Gender
Contact Material
Contact Plating
Contact Style
Current Rating
Fastening Type
Gender
Max Operating Temperature
Max Voltage Rating (DC)
Military Standard
Min Operating Temperature
Mount
Number of Contacts
Number of Ports
Number of Positions
Number of Terminals
Orientation
Packaging
Plating
Radiation Hardening
REACH SVHC
RoHS
Shell Material
Termination
Voltage Rating
Voltage Rating (DC)
Wire/Cable Gauge
Wire Gauge (Max)
Wire Gauge (Min)
Description
CSA, UL
Aluminium
Cadmium
Metal
Circular, Pin, Receptacle
Male
Brass
Silver
Pin
13 A
Threaded
Receptacle
125 °C
700.5 kV
MIL-DTL-5015
-55 °C
Cable, Free Hanging
7
1
7
7
Straight
Bulk
Cadmium, Chromate
No
Unknown
Non-Compliant
Aluminium
Solder
700 V
700 V
16 AWG
22 AWG
16 AWG
In Stock
Quantity
MOQ : 1
Per Unit Price
₹3082.86
Total Price
₹3082.86
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹3082.86
₹3082.86
10
₹2798.58
₹27985.79
25
₹2536.75
₹63418.63
