AD5628BCPZ-2-RL7
Manufacturer
Analog Devices
Description
DAC 8-CH Resistor-String 12-bit 16-Pin LFCSP EP T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Conversion Rate
Differential Output
Integral Nonlinearity (INL)
Interface
Lead Free
Lifecycle Status
Manufacturer Lifecycle Status
Max Input Voltage
Max Operating Temperature
Max Output Voltage
Max Power Dissipation
Max Supply Voltage
Min Input Voltage
Min Operating Temperature
Min Output Voltage
Min Supply Voltage
Number of Bits
Number of Channels
Number of Converters
Number of D/A Converters
Number of DAC Channels
Number of Pins
Output Type
Packaging
Polarity
Power Dissipation
REACH SVHC
Resolution
RoHS
Sampling Rate
Schedule B
Settling Time
Slew Rate
Description
LFCSP EP
95 ksps
No
1 LSB
SPI, Serial
Contains Lead
Production (Last Updated: 2 years ago)
PRODUCTION (Last Updated: 2 years ago)
5.5 V
105 °C
5 V
12.5 mW
5.5 V
2.7 V
-40 °C
0 V
2.7 V
12
8
8
8
8
16
Voltage
Cut Tape
Unipolar
12.4 mW
No
1.5 B
Compliant
95 ksps
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
6 µs
1.5 V/µs
In Stock
Quantity
MOQ : 1
Per Unit Price
₹2048.72
Total Price
₹2048.72
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹2048.72
₹2048.72
10
₹1467.18
₹14671.80
25
₹1313.78
₹32844.38
50
₹1313.79
₹65689.65
100
₹1205.96
₹120595.97
500
₹1205.96
₹602978.08
1000
₹1205.96
₹1205955.27
