DD540N22KHPSA2
Manufacturer
Infineon
Description
60 mm Rectifier Diode with 2200 V in pressure contact technology, BG-PB60AT-1-3, RoHS
Datasheet
DownloadProduct Attributes
Type
Case/Package
Forward Current
Forward Voltage
Halogen Free
Height
Lead Free
Lifecycle Status
Max Forward Surge Current (Ifsm)
Max Junction Temperature (Tj)
Max Operating Temperature
Max Output Current
Max Repetitive Reverse Voltage (Vrrm)
Min Operating Temperature
Number of Elements
Number of Pins
Number of Terminals
Output Current
Package Quantity
Peak Reverse Current
REACH SVHC
Reverse Standoff Voltage
Reverse Voltage
RoHS
Description
Module
540 A
1.48 V
Not Halogen Free
53 mm
Lead Free
Production (Last Updated: 9 months ago)
14 kA
150 °C
150 °C
540 A
2.6 kV
-40 °C
2
540
3
540 A
2
40 mA
Yes
2.2 kV
2.6 kV
Compliant
In Stock
Quantity
MOQ : 1
Minimum Qty : 1
Per Unit Price
₹21094.03
Total Price
₹21094.03
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹21094.03
₹21094.03
10
₹25133.53
₹251335.30
