DK1A-5V-F
Manufacturer
Panasonic
Description
Electromechanical Relay 5VDC 125Ohm 10A SPST-NO (20x12.5x10)mm THT Power Relay
Datasheet
DownloadProduct Attributes
Type
Ambient Temperature Range High
Approvals
Coil Current
Coil Power
Coil Resistance
Coil Type
Coil Voltage (DC)
Contact Current Rating
Contact Material
Current Rating
Depth
Fall Time
Height
Lead Free
Length
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Operate Time
Packaging
Power Consumption
Radiation Hardening
Ratings
REACH SVHC
Relay Type
Release Time
Response Time
RoHS
Switching Capacity
Switching Current
Termination
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Weight
Description
65 °C
CSA, TUV, UL, VDE
40 mA
200 mW
125 Ω
Non-Latching
5 V
10 A
Gold, Silver, Tin
10 A
12.5 mm
8 ms
10.3 mm
Lead Free
20 mm
10 A
65 °C
250 V
125 V
-40 °C
PCB , Through Hole
1
4
10 ms
Bulk
200 mW
No
IP67
No
General Purpose
8 ms
10 ms
Compliant
2.5 kW
10 A
PC Pin
SPST
250 V
125 V
5 g
In Stock
Quantity
MOQ : 1
Minimum Qty : 1
Per Unit Price
₹698.26
Total Price
₹698.26
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹698.26
₹698.26
10
₹549.24
₹5492.37
25
₹541.79
₹13544.71
50
₹534.34
₹26716.99
100
₹534.34
₹53433.99
500
₹534.34
₹267169.95
