DR127-680-R
Manufacturer
Eaton
Description
Ind Power Shielded Wirewound 68uH 20% 100KHz Ferrite 2.44A T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Length
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Packaging
Radiation Hardening
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Shielding
Termination
Test Frequency
Tolerance
Weight
Width
Description
Nonstandard
Wirewound
Ferrite
2.44 A
105 mΩ
12.5 mm
8 mm
8.001 mm
68 µH
20 %
Lead Free
12.5 mm
4.44 A
125 °C
Not
-40 °C
Surface Mount
2
Cut Tape
No
Unknown
2.44 A
Compliant
4.44 A
8504500000, 8504500000|8504500000, 8504500000|8504500000|8504500000, 8504500000|8504500000|8504500000|8504500000
100 kHz
Shielded
SMD/SMT
100 kHz
20 %
5.896701 g
12.4968 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹100.03
Total Price
₹100.03
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹100.03
₹100.03
10
₹75.76
₹757.60
25
₹75.72
₹1893.11
50
₹75.22
₹3760.94
100
₹62.30
₹6229.73
500
₹126.92
₹63461.32
1000
₹100.58
₹100577.41
