EEUED2C220
Manufacturer
Panasonic
Description
Radial Can ALUMINUM ELECTROLYTIC CAPACITOR ED 160V 22muF 20% 0.394Dia 10.00mm
Datasheet
DownloadProduct Attributes
Type
Capacitance
Case/Package
Contact Plating
Diameter
Dielectric Material
Dissipation Factor
Height
Height - Seated (Max)
Lead Diameter
Lead Free
Lead Pitch
Leakage Current
Length
Life (Hours)
Lifecycle Status
Max Operating Temperature
Min Operating Temperature
Mount
Number of Pins
Number of Terminals
Packaging
Radiation Hardening
REACH SVHC
Ripple Current
Ripple Current (AC)
RoHS
Schedule B
Terminal Pitch
Termination
Tolerance
Voltage
Voltage Rating
Voltage Rating (AC)
Voltage Rating (DC)
Description
22 µF
Radial
Tin
10 mm
Aluminium
15 %
22 mm
19.9898 mm
600 µm
Lead Free
5 mm
221.2 µA
20 mm
8000 hours
Production (Last Updated: 9 months ago)
105 °C
-25 °C
PCB, Through Hole
2
2
Bulk
No
Yes
200 mA
500 mA
Compliant
8532220020
5 mm
Radial
20 %
160 V
160 V
160 V
160 V
In Stock
Quantity
MOQ : 2
Minimum Qty : 2
Per Unit Price
₹81.11
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
10
₹46.12
₹461.16
25
₹46.10
₹1152.44
50
₹43.97
₹2198.32
100
₹35.87
₹3586.64
500
₹36.70
₹18347.58
1000
₹29.76
₹29763.12
