EPM9560ARC240-10
Manufacturer
Intel / Altera
Description
CPLD MAX 9000 Family 12K Gates 560 Macro Cells 144.9MHz 5V 240-Pin RQFP
Datasheet
DownloadProduct Attributes
Type
Case/Package
China RoHS
Clock Rate
Frequency
Height - Seated (Max)
Length
Lifecycle Status
Max Frequency
Max Operating Temperature
Max Supply Voltage
Memory Type
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Supply Current
Number of Gates
Number of I/Os
Number of Logic Blocks (LABs)
Number of Logic Elements/Cells
Number of Macrocells
Number of Pins
Number of Programmable I/O
Number of Terminals
Operating Supply Current
Operating Supply Voltage
Propagation Delay
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Speed Grade
Terminal Pitch
Turn-On Delay Time
Width
Description
QFP
Non-Compliant
144.9 MHz
144.9 MHz
4.1 mm
32 mm
Obsolete (Last Updated: 8 months ago)
144 MHz
70 °C
5.25 V
EEPROM
0 °C
4.75 V
Surface Mount
174 mA
12000
191
35
35
560
240
191
240
174 mA
5 V
11.4 ns
No
Yes
Non-Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
10
500 µm
10 ns
32 mm
Out of Stock
Quantity
MOQ : Unavailable
Minimum Qty : Unavailable
Per Unit Price
Unavailable
Total Price
Unavailable
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
