ERJP08F1502V

Manufacturer

Panasonic

Description

SMD Chip Resistor, 1206 [3216 Metric], 15 kohm, ERJP08 Series, 500 V, Thick Film, 660 mW

Datasheet

download datasheetDownload

Product Attributes

Type

Case/Package

Case Code (Imperial)

Case Code (Metric)

Composition

Contact Plating

Depth

Height

Length

Lifecycle Status

Max Operating Temperature

Military Standard

Min Operating Temperature

Mount

Number of Pins

Number of Terminals

Packaging

Power Dissipation

Power Rating

Radiation Hardening

REACH SVHC

Resistance

RoHS

Schedule B

Temperature Coefficient

Termination

Tolerance

Voltage Rating

Voltage Rating (DC)

Weight

Width

Working Voltage

Description

1206

1206

3216

Thick Film

Tin

1.6 mm

600 µm

3.2 mm

Production (Last Updated: 9 months ago)

155 °C

Not

-55 °C

Surface Mount

2

2

Cut Tape

660 mW

660 mW

No

Yes

15 kΩ

Compliant

8533210045, 8533210045|8533210045|8533210045|8533210045|8533210045

100 ppm/°C

SMD/SMT

1 %

500 V

200 V

16.187578 mg

1.6 mm

500 V

₹23.42

In Stock

Quantity
Shipment
delivery

Ships in 7-10 days

Add to Listarrow_icon

Quantity

Unit Price

Ext. Price

10

₹11.37

₹113.74

25

₹11.37

₹284.35

50

₹11.37

₹568.71

100

₹5.98

₹598.13

500

₹5.09

₹2546.60

1000

₹4.21

₹4205.10
