GBPC3502W
Manufacturer
onsemi
Description
GBPC Series 200V 400A Glass Passivated Single Phase Bridge Power Module - GBPC-W
Datasheet
DownloadProduct Attributes
Type
Average Rectified Current
Capacitance
Case/Package
China RoHS
Contact Plating
Current Rating
Element Configuration
Forward Current
Forward Voltage
Height
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Forward Surge Current (Ifsm)
Max Junction Temperature (Tj)
Max Operating Temperature
Max Output Current
Max Power Dissipation
Max Repetitive Reverse Voltage (Vrrm)
Max Surge Current
Min Breakdown Voltage
Min Operating Temperature
Mount
Number of Elements
Number of Pins
Number of Terminals
Output Current
Packaging
Peak Non-Repetitive Surge Current
Peak Reverse Current
Radiation Hardening
REACH SVHC
Reverse Standoff Voltage
Reverse Voltage
Reverse Voltage (DC)
RoHS
Schedule B
Voltage Rating (DC)
Weight
Width
Description
35 A
200 pF
Module
Non-Compliant
Nickel
35 A
Single
35 A
1.1 V
11.23 mm
Lead Free
29 mm
Production (Last Updated: 4 years ago)
ACTIVE (Last Updated: 4 years ago)
400 A
150 °C
150 °C
35 A
83.3 W
200 V
400 A
200 V
-55 °C
Through Hole
4
4
4
35 A
Bulk
400 A
5 µA
No
No SVHC
200 V
200 V
140 V
Compliant
8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080
200 V
17.21 g
29 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹669.57
Total Price
₹669.57
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹669.57
₹669.57
10
₹562.15
₹5621.52
25
₹562.08
₹14052.03
50
₹359.84
₹17992.07
100
₹348.67
₹34867.31
