HE2AN-DC24V
Manufacturer
Panasonic
Description
Relay Power DPST 277VAC 24VDC Quick Connect Carton/Case
Datasheet
DownloadProduct Attributes
Type
Ambient Temperature Range High
Approvals
Case/Package
Coil Current
Coil Power
Coil Resistance
Coil Type
Coil Voltage (DC)
Contact Current Rating
Contact Material
Contact Voltage Rating (AC)
Current Rating
Depth
Electrical Life
Height
Lead Free
Length
Lifecycle Status
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Manufacturer Package Identifier
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Operate Time
Packaging
Power Consumption
Radiation Hardening
Ratings
REACH SVHC
Relay Type
Release Time
Response Time
RoHS
Switching Capacity
Switching Current
Termination
Test Voltage
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Weight
Description
55 °C
CSA, TUV, UL, VDE
300
80 mA
1.92 W
300 Ω
Non-Latching
16.8 V
25 A
Silver, Tin
277 V
25 A
33 mm
100 kcycles
35.8 mm
Lead Free
50 mm
Production (Last Updated: 7 months ago)
25 A
55 °C
277 V
30 V
HE2AN-DC24V
-50 °C
Chassis Mount, PCB, Plug-In
2
6
30 ms
Box
1.92 W
No
IP40
Yes
General Purpose
10 ms
30 ms
Compliant
6.925 kW
25 A
Plug
10 kV
DPST
277 V
30 V
90 g
In Stock
Quantity
MOQ : 1
Per Unit Price
₹1587.22
Total Price
₹1587.22
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹1587.22
₹1587.22
10
₹1336.38
₹13363.79
25
₹1335.33
₹33383.24
50
₹1283.01
₹64150.67
100
₹1215.79
₹121578.54
