IDH09SG60CXKSA2
Manufacturer
Infineon
Description
Rectifier Diode, Schottky, 1 Phase, 1 Element, 9A, 600V V(RRM), Silicon Carbide, TO-220AC
Datasheet
DownloadProduct Attributes
Type
Average Rectified Current
Case/Package
China RoHS
Contact Plating
Element Configuration
Forward Current
Forward Voltage
Lifecycle Status
Max Forward Surge Current (Ifsm)
Max Operating Temperature
Max Output Current
Max Power Dissipation
Max Repetitive Reverse Voltage (Vrrm)
Max Reverse Voltage (DC)
Max Surge Current
Manufacturer Package Identifier
Min Operating Temperature
Number of Elements
Number of Pins
Number of Terminals
Package Quantity
Peak Non-Repetitive Surge Current
Peak Reverse Current
Power Dissipation
Radiation Hardening
REACH SVHC
Reverse Recovery Time
Reverse Standoff Voltage
RoHS
Schedule B
Description
9 A
TO-220-2
Compliant
Tin
Single
9 A
2.1 V
Obsolete (Last Updated: 9 months ago)
42 A
175 °C
9 A
115 W
600 V
600 V
49 A
PG-TO220-2
-55 °C
1
2
2
500
49 A
80 µA
115 W
No
Yes
0 s
600 V
Compliant
8541100080, 8541100080|8541100080, 8541100080|8541100080|8541100080, 8541100080|8541100080|8541100080|8541100080
Out of Stock
Ships in 7-10 days
