IHLP2020BZERR33M01
Manufacturer
Vishay
Description
Power Choke Shielded Wirewound 0.33uH 20% 100KHz Powdered Iron 12A 0.0082Ohm DCR 2020 T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Radiation Hardening
Resistance
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Description
2020
Wirewound
Composite, Ferrite, Metal
12 A
8.2 mΩ
5.43 mm
2 mm
2.0066 mm
330 nH
20 %
Lead Free
12 A
125 °C
Not
-55 °C
Surface Mount
No
7.6 mΩ
12 A
Compliant
25 A
8504500000
125 MHz
8.2 mΩ
Shielded
SMD/SMT
100 kHz
20 %
₹101.56
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹101.56
₹101.56
10
₹84.27
₹842.72
25
₹84.29
₹2107.24
50
₹84.29
₹4214.49
100
₹69.27
₹6927.47
500
₹69.28
₹34638.24
1000
₹56.99
₹56985.29
