IHLP3232DZER3R3M01
Manufacturer
Vishay
Description
Inductor Power Shielded Wirewound 3.3uH 20% 100KHz Powdered Iron 9.2A 17.7mOhm DCR 3232 T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Contact Plating
Core Material
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Radiation Hardening
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Description
3232
Wirewound
Tin
Ferrite
9.2 A
17.7 mΩ
8.94 mm
4 mm
3.9878 mm
3.3 µH
20 %
Lead Free
20 A
125 °C
Not
-55 °C
Surface Mount
2
No
Unknown
9.2 A
Compliant
20 A
8504500000, 8504500000|8504500000, 8504500000|8504500000|8504500000, 8504500000|8504500000|8504500000|8504500000
25 MHz
17.7 mΩ
Shielded
SMD/SMT
100 kHz
20 %
In Stock
Quantity
MOQ : 2
Minimum Qty : 2
Per Unit Price
₹87.98
Total Price
₹175.96
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹176.84
₹176.84
10
₹72.68
₹726.81
25
₹72.65
₹1816.15
50
₹72.56
₹3627.87
100
₹62.82
₹6282.24
500
₹62.82
₹31410.32
