IHLP6767GZER560M11
Manufacturer
Vishay
Description
Power Choke Shielded Wirewound 56uH 20% 100KHz Powdered Iron 7.2A 0.0578Ohm DCR 6767 T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Lead Free
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Radiation Hardening
REACH SVHC
Resistance
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Series Resistance
Shielding
Termination
Test Frequency
Tolerance
Width
Description
6767
Wirewound
Composite, Metal
7.2 A
57.8 mΩ
17.15 mm
7 mm
7.0104 mm
56 µH
20 %
Lead Free
4.2 A
125 °C
Not
-55 °C
Surface Mount
2
No
Unknown
55 mΩ
7.2 A
Compliant
4.2 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
2.9 MHz
57.8 mΩ
Shielded
SMD/SMT
100 kHz
20 %
17.145 mm
₹341.30
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹341.30
₹341.30
10
₹311.37
₹3113.74
25
₹311.36
₹7783.90
50
₹311.34
₹15566.90
100
₹311.34
₹31133.79
500
₹311.34
₹155668.95
1000
₹231.06
₹231055.80
