INA199A1RSWR
Manufacturer
Texas Instruments
Description
26V, bi-directional current sense amplifier 10-UQFN -40 to 125
Datasheet
DownloadProduct Attributes
Type
Common Mode Rejection Ratio
Gain Bandwidth Product
Height
Input Bias Current
Input Offset Voltage (Vos)
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Operating Temperature
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Supply Current
Number of Channels
Number of Circuits
Number of Elements
Number of Pins
Operating Supply Current
Output Type
Packaging
Power Supply Rejection Ratio (PSRR)
RoHS
Slew Rate
Thickness
Voltage Gain
Width
Description
100 dB
14 kHz
550 µm
28 µA
150 µV
Lead Free
1.8 mm
Production (Last Updated: 1 week ago)
ACTIVE (Last Updated: 1 week ago)
125 °C
26 V
-40 °C
2.5 V
Surface Mount
115 µA
1
1
1
10
65 µA
Voltage
Tape and Reel
140 dB
Compliant
0.4 V/µs
450 µm
33.98 dB
1.4 mm
In Stock
Quantity
MOQ : 3
Per Unit Price
₹45.35
Total Price
₹136.05
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹136.05
₹136.05
10
₹32.01
₹320.11
25
₹28.56
₹714.03
50
₹28.54
₹1427.17
100
₹24.74
₹2473.75
500
₹21.89
₹10946.05
1000
₹20.93
₹20931.77
