IPB014N06NATMA1
Manufacturer
Infineon
Description
Single N-Channel 60 V 1.4 mOhm 106 nC OptiMOS Power Mosfet - D2PAK-7
Datasheet
DownloadProduct Attributes
Type
Case/Package
Continuous Drain Current (ID)
Drain to Source Breakdown Voltage
Drain to Source Voltage (Vdss)
Fall Time
Gate to Source Voltage (Vgs)
Halogen Free
Input Capacitance
Lead Free
Lifecycle Status
Max Dual Supply Voltage
Max Operating Temperature
Max Power Dissipation
Min Operating Temperature
Mount
Number of Pins
On-State Resistance
Package Quantity
Packaging
Power Dissipation
Radiation Hardening
REACH SVHC
Rise Time
RoHS
Schedule B
Threshold Voltage
Turn-Off Delay Time
Turn-On Delay Time
Description
TO-263-7
180 A
60 V
60 V
14 ns
20 V
Halogen Free
7.8 nF
Contains Lead
Production (Last Updated: 4 years ago)
60 V
175 °C
214 W
-55 °C
Surface Mount
7
1.4 mΩ
1000
Tape & Reel
214 W
No
No
18 ns
Compliant
8541290080, 8541290080|8541290080|8541290080|8541290080|8541290080
2.8 V
47 ns
22 ns
In Stock
Quantity
MOQ : 1
Per Unit Price
₹378.93
Total Price
₹378.93
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹378.93
₹378.93
10
₹246.86
₹2468.60
25
₹246.86
₹6171.49
50
₹201.35
₹10067.63
100
₹201.35
₹20135.26
500
₹176.28
₹88141.06
1000
₹168.41
₹168405.59
