IPD135N03LGATMA1
Manufacturer
Infineon
Description
Single N-Channel 30 V 13.5 mOhm 6.4 nC OptiMOS Power Mosfet - TO-252-3
Datasheet
DownloadProduct Attributes
Type
Case/Package
Continuous Drain Current (ID)
Drain to Source Voltage (Vdss)
Element Configuration
Fall Time
Gate to Source Voltage (Vgs)
Height
Input Capacitance
Length
Lifecycle Status
Max Operating Temperature
Max Power Dissipation
Min Operating Temperature
Mount
Number of Pins
On-State Resistance
Package Quantity
Packaging
Power Dissipation
RoHS
Schedule B
Turn-Off Delay Time
Turn-On Delay Time
Width
Description
TO-252-3
30 A
30 V
Single
2.2 ns
20 V
2.41 mm
770 pF
6.73 mm
Production (Last Updated: 5 years ago)
175 °C
31 W
-55 °C
Surface Mount
3
13.5 mΩ
2500
Tape & Reel
31 W
Compliant
8541290080, 8541290080|8541290080|8541290080|8541290080|8541290080
12 ns
3 ns
6.22 mm
₹46.97
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
10
₹33.15
₹331.49
25
₹33.15
₹828.72
50
₹32.06
₹1602.86
100
₹30.96
₹3095.51
500
₹26.79
₹13396.40
1000
₹24.13
₹24128.50
