LM336M-2.5/NOPB
Manufacturer
Texas Instruments
Description
Voltage Ref, Shunt, 2.49V, SOIC-8; Volta; Msl: Msl 1 - Illimit; Svhc: No Svhc (15-JAN-2019)
Datasheet
DownloadProduct Attributes
Type
Case/Package
Current Rating
Height
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Operating Temperature
Max Output Current
Max Output Voltage
Min Operating Temperature
Min Output Voltage
Mount
Nominal Supply Current
Number of Channels
Number of Pins
Output Current
Output Voltage
Radiation Hardening
REACH SVHC
Reference Type
Reference Voltage
RoHS
Schedule B
Temperature Coefficient
Thickness
Tolerance
Width
Description
SOIC
10 A
1.75 mm
4.9 mm
Production (Last Updated: 5 days ago)
ACTIVE (Last Updated: 5 days ago)
70 °C
10 mA
2.49 V
0 °C
2.39 V
Surface Mount
400 µA
1
8
10 mA
2.5 V
No
No
Fixed, Shunt
2.5 V
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
20 ppm/°C
1.58 mm
4 %
3.91 mm
₹100.65
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹100.65
₹100.65
10
₹60.76
₹607.56
25
₹60.83
₹1520.73
50
₹56.97
₹2848.39
100
₹48.95
₹4895.25
500
₹48.95
₹24474.42
1000
₹46.64
₹46644.87
