M20-7820446
Manufacturer
Harwin
Description
2.54mm (0.1) Pitch SIL Vertical PC Tail Socket Assembly, tin, 4 contacts"
Datasheet
DownloadProduct Attributes
Type
Case/Package
Color
Connector Type
Contact Gender
Contact Material
Contact Plating
Current Rating
Depth
Gender
Hole Diameter
Housing Color
Housing Material
Insulation Resistance
Lead Pitch
Length
Max Current Rating
Max Operating Temperature
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Positions
Number of Rows
Orientation
Pitch
REACH SVHC
RoHS
Termination
Description
SIL
Black
Receptacle, Socket
Female
Bronze
Tin
3 A
2.5 mm
Receptacle
800 µm
Black
Polyamide
1 MΩ
2.54 mm
10.56 mm
3 A
105 °C
-40 °C
Through Hole
4
4
4
1
Straight
2.54 mm
No SVHC
Compliant
Solder
In Stock
Quantity
MOQ : 2
Per Unit Price
₹98.70
Total Price
₹197.40
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹197.40
₹197.40
10
₹61.94
₹619.40
25
₹61.94
₹1548.51
50
₹61.94
₹3097.03
100
₹61.94
₹6194.06
500
₹60.18
₹30088.71
1000
₹56.41
₹56409.96
