M80-5001042
Manufacturer
Harwin
Description
Conn Datamate Header 10 POS 2mm Solder ST Through Hole
Datasheet
DownloadProduct Attributes
Type
Color
Connector Type
Contact Gender
Contact Material
Contact Plating
Contact Resistance
Current Rating
Depth
Fastening Type
Flammability Rating
Gender
Height
Housing Color
Housing Material
Insulation Resistance
Lead Pitch
Length
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Positions
Number of Rows
Orientation
Pitch
Radiation Hardening
REACH SVHC
RoHS
Row Spacing
Termination
Voltage Rating
Voltage Rating (DC)
Width
Description
Black
Male Pin, Plug
Male
Gold, Nickel
Gold
25 mΩ
3 A
6.05 mm
Threaded
UL94 V-0
Male
5.6 mm
Black
Polyphenylene
100 MΩ
2 mm
20 mm
3 A
125 °C
120 V
120 V
-55 °C
Through Hole
10
10
10
2
Straight
2 mm
No
No
Compliant
2.0066 mm
Solder
800 V
120 V
5.55 mm
₹907.41
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹907.41
₹907.41
10
₹888.83
₹8888.31
25
₹888.83
₹22220.79
50
₹888.83
₹44441.56
100
₹870.25
₹87025.14
500
₹808.67
₹404335.35
1000
₹750.70
₹750699.85
