MAL215097001E3
Manufacturer
Vishay Beyschlag/Draloric/BC Components
Description
VISHAY - MAL215097001E3 - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 220 F, 35 V, 3000 hours @ 105C, Polar
Datasheet
DownloadProduct Attributes
Type
Capacitance
Tolerance
Voltage - Rated
Lifetime @ Temp.
Max Operating Temperature
Polarization
Ratings
Applications
Ripple Current (AC)
Impedance
Size / Dimension
Height - Seated (Max)
Surface Mount Land Size
Mounting Type
Case/Package
Description
220 µF
±20%
35 V
3000 Hrs @ 105°C
-55°C ~ 105°C
Polar
AEC-Q200
Automotive
409.5 mA @ 100 Hz
150 mOhms
0.394" Dia (10.00mm)
0.413" (10.50mm)
0.394" L x 0.394" W (10.00mm x 10.00mm)
Surface Mount
Radial, Can - SMD
₹294.60
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹294.60
₹294.60
10
₹206.34
₹2063.41
25
₹206.34
₹5158.54
50
₹162.84
₹8142.00
100
₹149.17
₹14916.67
500
₹107.27
₹53633.07
1000
₹102.17
₹102170.29
Product Attributes
Type
Capacitance
Tolerance
Voltage - Rated
Lifetime @ Temp.
Max Operating Temperature
Polarization
Ratings
Applications
Ripple Current (AC)
Impedance
Size / Dimension
Height - Seated (Max)
Surface Mount Land Size
Mounting Type
Case/Package
Description
220 µF
±20%
35 V
3000 Hrs @ 105°C
-55°C ~ 105°C
Polar
AEC-Q200
Automotive
409.5 mA @ 100 Hz
150 mOhms
0.394" Dia (10.00mm)
0.413" (10.50mm)
0.394" L x 0.394" W (10.00mm x 10.00mm)
Surface Mount
Radial, Can - SMD
