MCP1700T-3002E/MB
Manufacturer
Microchip
Description
Pwr Sply Func; Voltage Regulator; LDO; SOT-89; PD 1.635W; VO 3V; Regline +/-0.75%/V
Datasheet
DownloadProduct Attributes
Type
Projected EOL Date
Accuracy
Country of Origin
Dropout Voltage
Height
Input Bias Current
Introduction Date
Lead Free
Length
Lifecycle Status
Max Input Voltage
Max Operating Temperature
Max Output Current
Max Power Dissipation
Min Input Voltage
Min Operating Temperature
Min Output Voltage
Mount
Nominal Supply Current
Number of Channels
Number of Outputs
Number of Pins
Number of Regulators
Output Current
Output Type
Output Voltage
Output Voltage Accuracy
Polarity
Power Dissipation
Quiescent Current
Radiation Hardening
RoHS
Schedule B
Width
Description
2034-09-25
2 %
China, Taiwan
178 mV
1.6002 mm
1.6 µA
2003-09-25
Lead Free
4.5974 mm
Production (Last Updated: 4 years ago)
6 V
125 °C
200 mA
1.635 W
2.3 V
-40 °C
3 V
Surface Mount
4 µA
1
1
3
1
250 mA
Fixed
3 V
2 %
Positive
1.635 W
4 µA
No
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
2.5908 mm
In Stock
Quantity
MOQ : 3
Minimum Qty : 3
Per Unit Price
₹48.34
Total Price
₹145.01
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹145.89
₹145.89
10
₹48.28
₹482.77
25
₹40.67
₹1016.83
50
₹40.69
₹2034.54
100
₹36.90
₹3689.77
500
₹36.90
₹18448.83
1000
₹36.90
₹36897.67
