MDMK2020T3R3MM
Manufacturer
Taiyo Yuden
Description
Inductor Power Wirewound 3.3uH 20% 1MHz Metal 1.15A 0.178Ohm DCR T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Resistance (DCR)
Halogen Free
Height
Height - Seated (Max)
Inductance
Length
Max DC Current
Max Length
Max Operating Temperature
Max Saturation Current
Max Temperature Rise Current
Max Width
Min Length
Min Operating Temperature
Min Width
Mount
Packaging
Radiation Hardening
RoHS
Saturation Current
Schedule B
Shielding
Temperature Rise Current
Termination
Test Frequency
Tolerance
Width
Description
Nonstandard
Wirewound
Ferrite, Metal
1.15 A
155 mΩ
Halogen Free
1.2 mm
1.1938 mm
3.3 µH
2.0066 mm
1.15 A
2.15 mm
125 °C
1.35 A
1.15 A
2.15 mm
1.85 mm
-40 °C
1.85 mm
Surface Mount
Digi-Reel®
No
Compliant
1.55 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
Shielded
1.2 A
SMD/SMT
1 MHz
20 %
2 mm
In Stock
Quantity
MOQ : 4
Minimum Qty : 4
Per Unit Price
₹30.66
Total Price
₹122.63
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹123.51
₹123.51
10
₹25.23
₹252.31
25
₹25.20
₹629.89
50
₹25.18
₹1258.90
100
₹20.75
₹2074.93
500
₹20.75
₹10374.67
1000
₹17.06
₹17061.75
