MMBD2004SW-7-F
Manufacturer
Diodes Inc.
Description
Rectifier Diode Small Signal Switching 300V 0.225A 50ns 3-Pin SOT-323 T/R
Datasheet
DownloadProduct Attributes
Type
Average Rectified Current
Case/Package
China RoHS
Forward Current
Forward Voltage
Height
Length
Lifecycle Status
Max Forward Surge Current (Ifsm)
Max Operating Temperature
Max Output Current
Max Power Dissipation
Max Repetitive Reverse Voltage (Vrrm)
Max Reverse Voltage (DC)
Max Surge Current
Min Operating Temperature
Mount
Number of Elements
Number of Pins
Number of Terminals
Peak Non-Repetitive Surge Current
Peak Reverse Current
Power Rating
Radiation Hardening
REACH SVHC
Recovery Time
Reverse Recovery Time
Reverse Standoff Voltage
RoHS
Schedule B
Weight
Width
Description
225 mA
SOT-323
Compliant
225 mA
870 mV
1 mm
2.2 mm
Production (Last Updated: 9 months ago)
1 A
150 °C
225 mA
250 mW
300 V
240 V
4 A
-65 °C
Surface Mount
2
3
3
4 A
100 nA
250 mW
No
Yes
50 ns
50 ns
300 V
Compliant
8541100070
6.010099 mg
1.35 mm
In Stock
Quantity
MOQ : 4
Minimum Qty : 4
Per Unit Price
₹30.66
Total Price
₹122.63
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹123.51
₹123.51
10
₹20.82
₹208.20
25
₹20.87
₹521.82
50
₹20.84
₹1041.88
100
₹15.76
₹1576.49
500
₹15.77
₹7883.34
1000
₹11.43
₹11428.02
