NLV74VHC1G08DTT1G
Manufacturer
onsemi
Description
MC74VHC1G08 Series 2 to 5.5 SMT Single 2 Input AND Gate - SOT-23-5
Datasheet
DownloadProduct Attributes
Type
Case/Package
China RoHS
Height - Seated (Max)
High Level Output Current
Lead Free
Length
Lifecycle Status
Load Capacitance
Logic Function
Low Level Output Current
Manufacturer Lifecycle Status
Max Operating Temperature
Max Supply Current
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Number of Circuits
Number of Inputs
Number of Pins
Number of Terminals
Operating Supply Voltage
Packaging
Propagation Delay
Quiescent Current
REACH SVHC
RoHS
Schedule B
Schmitt Trigger Input
Terminal Pitch
Width
Description
TSOP
Compliant
1.1 mm
8 mA
Lead Free
3 mm
EOL (Last Updated: 1 year ago)
50 pF
AND
8 mA
LAST SHIPMENTS (Last Updated: 1 year ago)
125 °C
50 mA
5.5 V
-55 °C
2 V
Surface Mount
1
2
5
5
5 V
Tape & Reel (TR)
11 ns
1 µA
Yes
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
No
950 µm
1.5 mm
Out of Stock
Quantity
MOQ : Unavailable
Minimum Qty : Unavailable
Per Unit Price
Unavailable
Total Price
Unavailable
Ships in 7-10 days from Bengaluru
