PM5022S-330M-RC
Manufacturer
Bourns
Description
33 H Shielded Drum Core, Wirewound Inductor 2.5 A 83mOhm Nonstandard
Datasheet
DownloadProduct Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Drum Core, Wirewound
Ferrite
33 µH
±20%
2.5 A
5A
Shielded
83mOhm
44 @ 2.52MHz
10MHz
-40°C ~ 125°C
100 kHz
Surface Mount
Nonstandard
0.720" L x 0.551" W (18.30mm x 14.00mm)
0.280" (7.10mm)
₹128.03
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹128.03
₹128.03
10
₹68.62
₹686.20
25
₹68.62
₹1715.52
50
₹68.62
₹3431.02
100
₹68.62
₹6862.04
500
₹68.62
₹34310.22
1000
₹68.62
₹68620.45
Product Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Drum Core, Wirewound
Ferrite
33 µH
±20%
2.5 A
5A
Shielded
83mOhm
44 @ 2.52MHz
10MHz
-40°C ~ 125°C
100 kHz
Surface Mount
Nonstandard
0.720" L x 0.551" W (18.30mm x 14.00mm)
0.280" (7.10mm)
