PTN0603E5601JBBS
Manufacturer
Vishay
Description
Fixed Resistor, Thin Film, 0.15W, 5600ohm, 75V, 5% +/-Tol, 25ppm/Cel, Surface Mount, 0603
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Contact Plating
Height
Lead Free
Lifecycle Status
Max Operating Temperature
Min Operating Temperature
Mount
Number of Terminals
Operating Supply Voltage
Packaging
Power Dissipation
Power Rating
REACH SVHC
Resistance
RoHS
Temperature Coefficient
Thickness
Tolerance
Width
Working Voltage
Description
0603
Thin Film
Lead, Tin
508 µm
Lead Free
Production (Last Updated: 9 months ago)
155 °C
-55 °C
Surface Mount
2
75 V
Bulk
150 mW
150 mW
No
5.6 kΩ
Non-Compliant
25 ppm/°C
508 µm
5 %
812.8 µm
75 V
₹651.48
Out of Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹651.48
₹651.48
10
₹432.70
₹4327.03
25
₹432.76
₹10818.96
50
₹397.49
₹19874.72
100
₹377.91
₹37791.33
500
₹377.91
₹188956.65
1000
₹356.37
₹356374.20
