SCW08B-05

Manufacturer

Mean Well

Description

8 W; I/p: 18-36VDC; O/p: 05V @1600MA; D/d Module; Dc/dc; Module Type

Datasheet

download datasheetDownload

Product Attributes

Type

Approvals

Body Material

Case/Package

Current - Output 1

Depth

Efficiency

Height

Height - Seated (Max)

Isolation Voltage

Length

Lifecycle Status

Max Input Voltage

Max Operating Temperature

Max Output Current

Max Output Power

Max Output Voltage

Max Switching Frequency

Min Input Voltage

Min Operating Temperature

Min Output Voltage

Mount

Nominal Output Voltage

Number of Circuits

Number of Outputs

Number of Pins

Number of Terminals

Output Current

Output Power

Output Voltage

REACH SVHC

RoHS

Terminal Pitch

Voltage - Output 1

Width

Description

EN

Metal

DIP

1.6 A

20.3 mm

78 %

12.192 mm

12.7 mm

1 kV

31.8 mm

Production (Last Updated: 8 months ago)

36 V

71 °C

1.6 A

8 W

5.1 V

50 kHz

18 V

-40 °C

4.9 V

Through Hole

5 V

1

1

8

8

1.6 A

8 W

5 V

Yes

Compliant

2.54 mm

5 V

20.3 mm

In Stock


Quantity

MOQ : 1

decrement quantity
increment quantity

Per Unit Price

₹1872.65

Total Price

₹1872.65


delivery

Ships in 7-10 days from Bengaluru

Add to List

Quantity

Unit Price

Ext. Price

1

1872.65

1872.65

10

1825.97

18259.72
