SN74AVC4T774PWR
Manufacturer
Texas Instruments
Description
Voltage Level Translator 4-CH Bidirectional 16-Pin TSSOP T/R / IC BUS TRANSCVR 4BIT DL 16TSSOP
Datasheet
DownloadProduct Attributes
Type
Case/Package
Data Rate
Direction
Height
High Level Output Current
Lead Free
Length
Lifecycle Status
Logic Function
Low Level Output Current
Manufacturer Lifecycle Status
Max Junction Temperature (Tj)
Max Operating Temperature
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Number of Bits
Number of Channels
Number of Circuits
Number of Elements
Number of Inputs
Number of Outputs
Number of Pins
Output Current
Polarity
Propagation Delay
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Thickness
Turn-On Delay Time
Weight
Width
Description
TSSOP
380 mbps
Bidirectional
1.2 mm
-12 mA
Lead Free
5 mm
Production (Last Updated: 3 days ago)
Transceiver, Translator
12 mA
ACTIVE (Last Updated: 3 days ago)
150 °C
85 °C
3.6 V
-40 °C
1.2 V
Surface Mount
4
4
4
1
4
2
16
12 mA
Non-Inverting
2.4 ns
No
No SVHC
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
1 mm
8.2 ns
59.987591 mg
4.4 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹112.93
Total Price
₹112.93
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹112.93
₹112.93
10
₹74.25
₹742.48
25
₹74.12
₹1853.09
50
₹74.14
₹3707.07
100
₹61.46
₹6146.15
500
₹58.97
₹29486.76
1000
₹56.94
₹56937.25
