SN75160BN
Manufacturer
Texas Instruments
Description
Line Transceiver, 8 Func, 8 Driver, 8 Rcvr, BIPolar, PDIP20
Product Attributes
Type
Case/Package
Height
High Level Output Current
Lead Free
Length
Lifecycle Status
Logic Function
Low Level Output Current
Manufacturer Lifecycle Status
Max Operating Temperature
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Supply Current
Number of Channels
Number of Circuits
Number of Drivers
Number of Pins
Number of Receivers
Number of Transceivers
Number of Transmitters
Operating Supply Current
Operating Supply Voltage
Propagation Delay
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Termination
Thickness
Weight
Width
Description
PDIP
5.08 mm
-5.2 mA
Lead Free
24.33 mm
Production (Last Updated: 1 year ago)
Transceiver
48 mA
ACTIVE (Last Updated: 3 days ago)
70 °C
5.25 V
0 °C
4.75 V
Through Hole
85 mA
8
8
8
20
8
1
8
110 mA
5 V
22 ns
No
No
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
Through Hole
4.57 mm
1.1991 g
6.35 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹467.72
Total Price
₹467.72
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹467.72
₹467.72
10
₹460.78
₹4607.83
25
₹333.07
₹8326.69
50
₹314.63
₹15731.73
100
₹295.45
₹29544.56
500
₹271.97
₹135982.69
