SPM10054T-4R7M-HZR
Manufacturer
TDK
Description
TDK - SPM10054T-4R7M-HZR - Power Inductor (SMD), 4.7 H, 9.5 A, Shielded, 12.2 A, SPM-HZR Series
Datasheet
DownloadProduct Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Wirewound
Metal
4.7 µH
±20%
9.5 A
12.2A
Shielded
14mOhm Max
AEC-Q200
-40°C ~ 125°C
100 kHz
Surface Mount
Nonstandard
0.421" L x 0.394" W (10.70mm x 10.00mm)
0.213" (5.40mm)
₹262.43
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹262.43
₹262.43
10
₹215.91
₹2159.06
25
₹189.89
₹4747.34
50
₹188.76
₹9437.99
100
₹177.11
₹17711.39
500
₹150.39
₹75197.02
Product Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Wirewound
Metal
4.7 µH
±20%
9.5 A
12.2A
Shielded
14mOhm Max
AEC-Q200
-40°C ~ 125°C
100 kHz
Surface Mount
Nonstandard
0.421" L x 0.394" W (10.70mm x 10.00mm)
0.213" (5.40mm)
