SRN5040-330M
Manufacturer
Bourns
Description
Ind Power Semi-Shielded Wirewound 33uH 20% 100KHz Ferrite 1.2A 5040 T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Current
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Length
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Shielding
Termination
Test Frequency
Tolerance
Weight
Width
Description
2020
Wirewound
Ferrite
1.2 A
1.2 A
216 mΩ
5.2 mm
4 mm
3.9878 mm
33 µH
20 %
5 mm
1.2 A
125 °C
Not
-40 °C
Surface Mount
No
1.2 A
Compliant
1.3 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
8 MHz
Shielded
SMD/SMT
100 kHz
20 %
299.994654 mg
5.0038 mm
In Stock
Quantity
MOQ : 3
Minimum Qty : 3
Per Unit Price
₹37.85
Total Price
₹113.55
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹113.55
₹113.55
10
₹32.04
₹320.39
25
₹31.99
₹799.66
50
₹31.90
₹1594.92
100
₹26.71
₹2671.41
500
₹26.71
₹13356.16
1000
₹20.80
₹20799.13
