SRP1050WA-220M
Manufacturer
Bourns
Description
BOURNS - SRP1050WA-220M - Power Inductor (SMD), 22 H, 6 A, Shielded, 8.8 A, SRP1050WA Series
Datasheet
DownloadProduct Attributes
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Alloy Powder
22 µH
±20%
6 A
8.8A
Shielded
50mOhm Max
20 @ 100kHz
7MHz
AEC-Q200
-55°C ~ 165°C
100 kHz
Surface Mount
Nonstandard
0.433" L x 0.394" W (11.00mm x 10.00mm)
0.213" (5.40mm)
₹152.81
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹152.81
₹152.81
10
₹125.35
₹1253.55
25
₹109.36
₹2734.02
50
₹109.34
₹5467.13
100
₹103.09
₹10309.31
500
₹89.84
₹44918.26
1000
₹82.02
₹82024.26
Product Attributes
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Alloy Powder
22 µH
±20%
6 A
8.8A
Shielded
50mOhm Max
20 @ 100kHz
7MHz
AEC-Q200
-55°C ~ 165°C
100 kHz
Surface Mount
Nonstandard
0.433" L x 0.394" W (11.00mm x 10.00mm)
0.213" (5.40mm)
