SRP1265A-5R6M
Manufacturer
Bourns
Description
Inductor Power Shielded Wirewound 5.6uH 20% 100KHz 20Q-Factor Carbonyl Powder 12.5A 10mOhm DCR Automotive T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Current
DC Resistance (DCR)
Depth
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Length
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Ratings
REACH SVHC
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Shielding
Termination
Test Frequency
Tolerance
Width
Description
Nonstandard
Wirewound
Carbonyl Powder
12.5 A
12.5 A
10 mΩ
12.8 mm
6.2 mm
6.4008 mm
5.6 µH
20 %
13.4874 mm
12.5 A
150 °C
Not
-40 °C
Surface Mount
AEC-Q200
No
12.5 A
Compliant
23 A
8504500000, 8504500000|8504500000|8504500000|8504500000|8504500000
15 MHz
Shielded
SMD/SMT
100 kHz
20 %
12.4968 mm
In Stock
Quantity
MOQ : 1
Minimum Qty : 1
Per Unit Price
₹140.27
Total Price
₹140.27
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹140.27
₹140.27
10
₹100.75
₹1007.47
25
₹100.75
₹2518.68
50
₹93.64
₹4682.13
100
₹85.23
₹8523.44
500
₹82.78
₹41390.18
1000
₹78.06
₹78061.47
