SRP5030TA-100M
Manufacturer
Bourns
Description
BOURNS - SRP5030TA-100M - Power Inductor (SMD), 10 H, 2.75 A, Shielded, 3.5 A, SRP5030TA Series
Datasheet
DownloadProduct Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Drum Core, Wirewound
Carbonyl Powder
10 µH
±20%
2.75 A
3.5A
Shielded
128mOhm Max
20 @ 100kHz
18MHz
AEC-Q200
-40°C ~ 150°C
100 kHz
Surface Mount
Nonstandard
0.224" L x 0.205" W (5.70mm x 5.20mm)
0.118" (3.00mm)
₹132.54
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹132.54
₹132.54
10
₹108.72
₹1087.21
25
₹94.82
₹2370.50
50
₹94.82
₹4741.00
100
₹89.47
₹8947.07
500
₹79.53
₹39766.24
1000
₹75.06
₹75063.62
Product Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Drum Core, Wirewound
Carbonyl Powder
10 µH
±20%
2.75 A
3.5A
Shielded
128mOhm Max
20 @ 100kHz
18MHz
AEC-Q200
-40°C ~ 150°C
100 kHz
Surface Mount
Nonstandard
0.224" L x 0.205" W (5.70mm x 5.20mm)
0.118" (3.00mm)
