SRR1260-680M
Manufacturer
Bourns
Description
Ind Power Shielded Wirewound 68uH 20% 100KHz 22Q-Factor Ferrite 2.1A T/R
Datasheet
DownloadProduct Attributes
Type
Case/Package
Composition
Core Material
Current Rating
DC Current
DC Resistance (DCR)
Depth
Frequency
Height
Height - Seated (Max)
Inductance
Inductance Tolerance
Length
Material
Max DC Current
Max Operating Temperature
Military Standard
Min Operating Temperature
Mount
Number of Pins
Packaging
Q Factor
REACH SVHC
Resistance
RMS Current (Irms)
RoHS
Saturation Current
Schedule B
Self Resonant Frequency
Shielding
Termination
Test Frequency
Tolerance
Width
Description
1260
Wirewound
Ferrite
2.1 A
2.1 A
110 mΩ
12.8 mm
7.43 MHz
6 mm
6.5024 mm
68 µH
20 %
12.5 mm
Steel
2.1 A
125 °C
Not
-40 °C
Surface Mount
2
Cut Tape
22
No
110 MΩ
2.1 A
Compliant
2.1 A
8504500000, 8504500000|8504500000, 8504500000|8504500000|8504500000, 8504500000|8504500000|8504500000|8504500000
7.43 MHz
Shielded
SMD/SMT
100 kHz
20 %
12.5 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹105.40
Total Price
₹105.40
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹105.40
₹105.40
10
₹88.48
₹884.75
25
₹88.53
₹2213.22
50
₹84.69
₹4234.73
100
₹72.79
₹7278.99
500
₹69.14
₹34568.73
1000
₹61.05
₹61053.02
