SRR1260A-330M
Manufacturer
Bourns
Description
BOURNS - SRR1260A-330M - Power Inductor (SMD), 33 H, 3 A, Shielded, 2.8 A, SRR1260A Series
Datasheet
DownloadProduct Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Drum Core, Wirewound
Ferrite
33 µH
±20%
3 A
2.8A
Shielded
60mOhm Max
27 @ 2.52MHz
9.97MHz
AEC-Q200
-40°C ~ 125°C
1 kHz
Surface Mount
Nonstandard
0.492" L x 0.492" W (12.50mm x 12.50mm)
0.256" (6.50mm)
₹165.68
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹165.68
₹165.68
10
₹136.37
₹1363.74
25
₹118.52
₹2963.12
50
₹118.53
₹5926.25
100
₹111.78
₹11177.50
500
₹98.26
₹49130.85
1000
₹86.16
₹86162.41
Product Attributes
Type
Type
Core Material
Inductance
Tolerance
Current Rating (Amps)
Saturation Current
Shielding
DC Resistance (DCR)
Q @ Freq
Frequency - Self Resonant
Ratings
Max Operating Temperature
Inductance Frequency - Test
Mounting Type
Case/Package
Size / Dimension
Height - Seated (Max)
Description
Drum Core, Wirewound
Ferrite
33 µH
±20%
3 A
2.8A
Shielded
60mOhm Max
27 @ 2.52MHz
9.97MHz
AEC-Q200
-40°C ~ 125°C
1 kHz
Surface Mount
Nonstandard
0.492" L x 0.492" W (12.50mm x 12.50mm)
0.256" (6.50mm)
