SSG-01H
Manufacturer
Omron
Description
Switch Snap Action N.O./N.C. SPDT Pin Plunger 0.1A 125VAC 30VDC 1.5N Screw Mount Solder Lug
Datasheet
DownloadProduct Attributes
Type
Case/Package
Contact Current Rating
Contact Material
Contact Voltage Rating (AC)
Current Rating
Depth
Differential Travel
Electrical Life
Height
Length
Lifecycle Status
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Mechanical Life
Min Operating Temperature
Mount
Number of Positions
Operating Force
Operating Position
Overtravel
Pretravel
Radiation Hardening
Ratings
REACH SVHC
RoHS
Sealable
Switch Function
Termination
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Description
100
100 mA
Gold
125 V
100 mA
6.4 mm
101.6 µm
200 kcycles
9.9 mm
19.8 mm
Production (Last Updated: 7 months ago)
100 mA
125 °C
250 V
30 V
10 Mcycles
-25 °C
Chassis Mount, Panel, Screw
2
1.5 N
8.382 mm
381 µm
600 µm
No
IP40
Unknown
Compliant
IP00
On-Mom
Solder
SPDT
125 V
30 V
In Stock
Quantity
MOQ : 1
Per Unit Price
₹266.76
Total Price
₹266.76
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹266.76
₹266.76
10
₹194.73
₹1947.35
25
₹195.20
₹4879.93
